Southland 107-554NL Ball Valve, 3/4 in Connection, Compression, 500 psi Pressure, Brass Body
- Body Material: Brass
- Connection Size: 3/4 in
- Connection Type: Compression
- Finish: Chrome
- Media: Gas Oil Steam Water
- Model #: 107-554NL
- UPC #: 032888110472
- SKU: 6446652
- B_K_107_553NL_Catalog.pdf
- Application: For rough plumbing and mechanical application
Product Overview
Product Details
-20 to 300 deg F temperature range, full port, PTFE seat and packing, chrome-plated brass ball and stem, suitable for vacuum use up to 7 psia, port allows non-pressure side to drain when closed, solder ends comply with ANSI B16.18, IAPMO listed to cUPC, certified to NSF 61-G.Item Specifications
| Body Material | Brass |
|---|---|
| Connection Size | 3/4 in |
| Connection Type | Compression |
| Finish | Chrome |
| Media | Gas Oil Steam Water |
| Number of Ports/Ways | 2 |
|---|---|
| Pressure Rating | 500 psi |
| Temperature Rating | -20 to 300 deg F |
| Trim Material | Brass/PTFE |
